Colours

Stealth Chrome, Plasma Coral

Frame

ALUXX-grade aluminum, disc

Fork

SXC32-2 RCL, air spring, thru axle, steel steerer, 15x110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)

Handlebar

Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29)

Grips

Giant Sole-O

Stem

Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29)

Seatpost

Contact Switch AT Core, 30.9, dropper, remote under bar, 110-140mm travel XS: 395mm (27.5) S: 395mm (27.5/29) M: 395mm (29) L: 395mm (29) XL: 395mm (29) XXL: 395mm (29)

Saddle

Giant ErgoContact Trail

Pedals

platform

Shifters

Shimano Deore M6200, 1x12

Rear Derailleur

Shimano Deore M7200, Shadow ES

Brakes

Shimano BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm

Brake Levers

Shimano BL-MT201

Cassette

Shimano Deore M6200, 10x51

Chain

KMC X-12

Crankset

ProWheel MPX, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29)

Bottom Bracket

Cartridge

Rims

Giant tubeless compatible 29 or 27.5, alloy, double wall, 21mm inner width

Hubs

[F] Shimano, sealed bearing, 15x110 thru axle, [R] 12x142 thru-axle

Spokes

stainless, 14g

Tires

Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", wire bead

Max Tire Clearance

2.4"

Max Chainring Size

32T
