Frame

300 Series Alpha Aluminum, TQ drive system, hidden fender mounts, rack mounts, integrated frame bag mounts, internal cable routing, flat mount disc, integrated chainkeeper, UDH, 142x12mm chamfered thru axle

Fork

Domane+ carbon, tapered carbon steerer, fender mounts, flat mount disc, 12x100mm thru axle

Weight

ML - 14.39 kg / 31.73 lbs (with TLR sealant, no tubes)

Battery

TQ 360Wh

Charger

TQ 2A charger

Controller

TQ color LED display with Bluetooth & ANT+ connectivity

Computer

TQ LED display with Bluetooth & ANT+ connectivity

Motor

TQ-HPR60, 60 Nm, 250 watt maximum continuous rated power, 350 watt peak power

E-bike Classification

• Class 1
• Max assist speed: 32 km/h

Shifter

SRAM Apex, 12 speed

Rear derailleur

SRAM Apex XPLR, 44T max cog

Crank

• Size: XS, S: Praxis Alloy, 165mm length
• Size: M, ML: Praxis Alloy, 170mm length
• Size: L, XL: Praxis Alloy, 172.5mm length

Cassette

SRAM XPLR PG-1231, 11-44, 12 speed

Chain

SRAM Apex, 12 speed

Max chainring size

1x: 46T

Hub front

Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle

Rim

Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23mm width, Presta valve

Tires

• Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm
• Bontrager TLR sealant, 180 ml/6 oz
• Max tire size: 40mm without fenders, 35mm with fenders

Saddle

Verse Short Comp, steel rails, 145mm width

Seatpost

Bontrager alloy, 27.2mm, 12mm offset, 330mm length

Handlebar

• Size: XS: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control width, 40cm drop width
• Size: S: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm drop width
• Size: M, ML: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control width, 44cm drop width
• Size: L, XL: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm drop width

Handlebar tape

Trek EcoTack

Stem

• Size: XS:Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
• Size: S: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
• Size: M: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
• Size: ML, L: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length
• Size: XL: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length

Brake

• SRAM Apex D1 hydraulic disc, flat mount
• Brake rotor: SRAM Paceline, rounded, centerlock, 160mm
• Brake lever: SRAM Apex, 12 speed
• Rotor size: Max brake rotor sizes: 160mm front & rear
